Shavison Relay AS363-24V-OE

650 INR/Piece

Minimum Order Quantity : 1 Pieces

Get a Price/Quote

Request To Call Back

Shavison Relay AS363-24V-OE Price & Specifications

Working Temperature -25A C to +55A C

Weight Approximately 50 g

Usage General Purpose, Industrial, Automation

Theory Electromagnetic Relay

Terminal Type Plug-in

Supply Terminal Screw Terminal

Size Standard Miniature

Rated Voltage 24V DC

Protect Feature With Dust Cover

Product Type Electromechanical Relay

Power Consumption Approx. 0.9W

Operate Time 15 ms Max.

Mechanical Life 10,000,000 Operations Min.

Insulation Resistance 100 MIC Min. (at 500VDC)

Dimension (L*W*H) 28 mm A 21 mm A 35 mm approx.

Dielectiric Strength 1,000VAC, 50/60Hz for 1 min between coil & contact

Contact Resistance 50 mIC Max. (Initial)

Contact Material Silver Alloy

Contact Load 10A at 250V AC / 30V DC

Contact Form DPDT (2CO)

Color Black / Transparent Cover

Coil Voltage 24V DC

Coil Power 0.9W

Ambient Temperature -25A C to +55A C

About Shavison Relay AS363-24V-OE Detail

ShavisonAS363-24V-OE - Dealer, Supplier

Weare dealer and supplier of Shavison AS363-24V-OE in India, Mumbai,Delhi, Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur,Vapi, Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore,Bhopal, Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad, Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia. We areDealer, Supplier of Shavison SMPS,Shavison Relay Module, Shavison Battery Charger.

Reliable Automation Component

The Shavison AS363-24V-OE relay brings precision and dependability to automation projects and control systems. Its robust engineering enables it to withstand mechanical shocks up to 100 m/s2 and vibrations between 10-55 Hz, making it highly suitable for industrial environments. The relay's quick response times and dust-protected design ensure consistent performance in demanding applications.

Versatile Installation and Design

With a standard miniature size (28 21 35 mm) and plug-in socket mounting, this relay integrates seamlessly into control panels, PLC interfaces, and electrical panels. The screw terminal supply simplifies wiring, while the transparent cover aids in visual inspection. The relay's DPDT contacts made from silver alloy offer excellent conductivity and durability for general industrial use.

FAQ's of Shavison Relay AS363-24V-OE:

Q: How do I install the Shavison AS363-24V-OE relay in an automation system?

A: To install the Shavison AS363-24V-OE, plug the relay into a compatible socket and connect your control circuits to the screw terminals as per your wiring diagram. Always ensure the rated voltage and coil resistance match your system requirements.

Q: What applications can the AS363-24V-OE relay be used for?

A: This relay is designed for general purpose, industrial, and automation use such as in control panels, PLC interfaces, machine automation, and electrical panels. Its robust construction and dependable switching performance make it suitable for these contexts.

Q: When does the relay activate, and what is its response time?

A: The relay activates when the coil receives at least 19.2V DC (the minimum pick-up voltage), with an operate time of up to 15 ms and release time of up to 10 ms, ensuring fast response in automation systems.

Q: Where can this relay be used in terms of environmental conditions?

A: It operates reliably in ambient and working temperatures ranging from -25C to +55C and can be stored at -40C to +70C. Its dust cover and vibration resistance make it ideal for harsh industrial settings.

Q: What is the process for ensuring long-term reliability of the relay?

A: Maintain the relay within its rated temperature, voltage, and load specifications. Regularly check insulation resistance and the dust cover for integrity. With a mechanical life of at least 10,000,000 operations, it offers dependable service with routine monitoring.

Q: How does the Shavison relay benefit industrial automation projects?

A: By providing quick switching, high load capacity, and robust mechanical design, this relay improves system reliability, maintains operational safety, and reduces downtime in automation and control environments.
