BTH PSAZ-25-1/2-P Magnetic Sensor

250 INR/Piece

Minimum Order Quantity : 1 Pieces

Get a Price/Quote

Request To Call Back

BTH PSAZ-25-1/2-P Magnetic Sensor Price & Specifications

Wireless No

Weight Approx. 50 g

Voltage 12-24V DC

Usage Pneumatic Cylinder Sensing

Signal Type Digital

Sensor Type Reed Switch / Magnetic Proximity

Sensitivity High

Response Time a 1 ms

Resolution High

Product Type Magnetic Sensor

Power Consumption <10 mA

Output PNP NO (Normally Open)

Operating Temperature -20A C to +70A C

Mounting Type Clamp-on / Slot Mount

Measurement Range Up to 25 mm Cylinder Bore

Material ABS Plastic Housing

Interface 3-wire

Input 12-24V DC

IP Rating IP67

Function Position Detection

Features Compact design, Easy installation, LED indicator

Cable Length 2 Meter

Application Industrial Automation, Pneumatics

Accuracy A 1 mm

About BTH PSAZ-25-1/2-P Magnetic Sensor Detail

BTHPSAZ-25-1/2-P MagneticSensor- Dealer, Supplier

Weare dealer and supplier of PSAZ-25-1/2-PMagneticSensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Weare dealer, supplier of various manufacture of Bth Motion, BthEncoder Bth Pressure, Bth Process & Sensor Controller, Bth ReedSensor, Bth Inductive Sensor, Bth Analog & Capacitive Sensor, BthSensor Cable, Bth Photo sensor , Bth Fiber Sensor, Bth LiquidSensing, Bth SSR, Bth TPR, Bth DC Supply, Bth Signal.

Reliable Position Detection for Pneumatic Cylinders

The BTH PSAZ-25-1/2-P Magnetic Sensor delivers precise position detection, specifically designed for standard T-slot pneumatic cylinders. Its 1 mm accuracy and high-resolution sensing ensure optimal performance in automation systems requiring accurate cylinder movement monitoring.

Durable and Easy to Install

Featuring an IP67 ABS plastic housing, the sensor withstands harsh industrial settings with strong vibration and shock resistance. Its compact structure, clamp-on/slot mount design, and pre-wired 2-meter cable allow for quick, hassle-free installation and maintenance.

Efficient Performance with LED Indicator

Equipped with a clear LED indicator, this sensor provides immediate visual feedback of operational status. Its digital PNP NO output, low power consumption, and quick response (1 ms) support efficient, reliable integration into control systems for industrial automation and pneumatics.

FAQ's of BTH PSAZ-25-1/2-P Magnetic Sensor:

Q: How do I install the BTH PSAZ-25-1/2-P Magnetic Sensor on my pneumatic cylinder?

A: Mount the sensor directly into the T-slot of any standard pneumatic cylinder using the provided clamp-on or slot mount. Once in place, connect the pre-wired 2-meter PVC cable to your control system, ensuring you observe correct 3-wire PNP NO wiring for 12-24V DC input.

Q: What operational environments is this sensor suited for?

A: The sensor is built to work reliably in industrial environments, withstanding shock up to 30G, vibrations from 10-55 Hz (1.5 mm amplitude), humidity levels from 35% to 85% RH, and temperatures between -20C and +70C during operation and -25C to +80C in storage.

Q: Where can this magnetic sensor be used within industrial automation?

A: It is ideal for applications requiring precise pneumatic cylinder position sensing, including packaging machines, assembly lines, robotics, and other automated processes where monitoring cylinder movement is critical.

Q: What is the process of verifying sensor operation?

A: Simply observe the integrated LED indicator while the sensor is powered and installed. When a magnetic field from the cylinder's piston is detected, the LED illuminates, confirming a properly functioning sensor and the closing of the PNP NO contact.

Q: What are the key usage benefits of this magnetic sensor?

A: The sensor provides high-resolution, accurate position detection (1 mm) with a rapid response time (1 ms). Its robust and sealed design ensures long-term reliability, while features like the LED indicator and pre-wired connection simplify both setup and ongoing use.

Q: How does the BTH PSAZ-25-1/2-P ensure safety and durability?

A: Constructed with ABS plastic housing and rated IP67, the sensor is dust-tight and water-resistant, minimizing maintenance needs. Its high insulation resistance (100 M min at 500VDC) and strong shock/vibration tolerances make it dependable for demanding industrial settings.

Q: What is the maximum switching capacity of the sensor?

A: This sensor supports a maximum switching voltage of 100V DC and a switching current of up to 100 mA, accommodating a wide range of industrial control and automation applications.
