BTH SENSOR

(252 products available)

Discover the strength and durability of our BTH SENSOR, a peerless addition to your technological arsenal, showcasing marvelous features and outstanding performance. With an experience of over 16.0 years, our product lineup includes the BTH BAR18 OM8N Liner Analog Inductive Sensor, BTH BI-52S-720-PU Magnetic Sensor, BTH BIT6.5-PN2F-18 Magnetic Sensor, BTH KT-20N-1M Magnetic Sensor, and BTH KT-48R-1M Magnetic Sensor, each offering the lowest price in the market. This hot deal caters to your needs as an exporter in Asia and as a supplier to the domestic market across All India. Find unparalleled advantages and features with the BTH SENSOR, ensuring top-notch quality, reliability, precision, and innovation for your business needs. Trust in our product to elevate your operations and deliver unparalleled results in the field of sensors.

View More Details

BTH PSAZ-80-P-1 Magnetic Sensor

450 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight 15 g

Voltage 12-24V DC

Usage Detecting Magnetic Field/Proximity

Signal Type Digital

Sensor Type Reed Switch Type Magnetic Sensor

Sensitivity High

Response Time a 1 ms

Resolution 0.1 mm

Product Type Magnetic Sensor

Power Consumption 10 mA (max)

Output PNP, Normally Open

Operating Temperature -10A C to +70A C

Mounting Type Clamp Mount with Screw

Measurement Range 0-15 mm

Material Plastic

Interface 2-wire

Input 12-24V DC

IP Rating IP67

Function Position Sensing

Features LED Indicator, Compact Design

Cable Length 2 m

Application Industrial Automation, Pneumatic Cylinder Feedback

Accuracy A 1 mm

About this product

BTHPSAZ-80-P-1 MagneticSensor- Dealer, Supplier

Weare dealer and supplier of PSAZ-80-P-1MagneticSensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Weare dealer, supplier of various manufacture of Bth Motion, BthEncoder Bth Pressure, Bth Process & Sensor Controller, Bth ReedSensor, Bth Inductive Sensor, Bth Analog & Capacitive Sensor, BthSensor Cable, Bth Photo sensor , Bth Fiber Sensor, Bth LiquidSensing, Bth SSR, Bth TPR, Bth DC Supply, Bth Signal.

Exceptional Sensing Performance

Engineered for high sensitivity, the PSAZ-80-P-1 sensor delivers precise magnetic field detection with quick response times of 1 ms. Its 1 mm accuracy and 0.1 mm resolution ensure reliable feedback, making it ideal for position sensing in automation and pneumatic cylinder systems.

Robust and Versatile Design

Encapsulated in a plastic housing, the sensor resists shock, vibration, moisture, and dust (IP67 rated), functioning reliably in harsh conditions. The pre-wired 2-meter cable, clamp mount, and rhodium-plated contacts enhance ease of installation and long-term durability.

Certified for Industrial Reliability

With CE marking and rigorous build standards, this sensor meets international safety and quality certifications. Its operating temperature range (-10C to +70C) and storage range (-25C to +80C) allow for flexible deployment in diverse environments globally, including India.

FAQ's of BTH PSAZ-80-P-1 Magnetic Sensor:

Q: How is the BTH PSAZ-80-P-1 Magnetic Sensor installed in an industrial environment?

A: The sensor is installed using its clamp mount with screws, providing a secure fit onto pneumatic cylinders or other machinery. The pre-wired cable allows straightforward electrical connections, while the compact design and 30 mm bend radius make routing the cable easy even in confined spaces.

Q: What applications are suitable for this magnetic sensor?

A: It is best suited for industrial automation tasks, such as position detection and feedback on pneumatic cylinders. Producers, manufacturers, and system integrators in India can benefit from its reliable performance for proximity detection and magnetic field sensing in various automation setups.

Q: When should the sensor be used for feedback on pneumatic cylinders?

A: Use the sensor during operations requiring precise real-time position feedback of pneumatic cylinder magnets. Its high sensitivity and quick response time enable accurate monitoring, ensuring efficient automation and process control.

Q: Where can I deploy the sensor, considering its environmental specifications?

A: With shock and vibration resistance, IP67 ingress protection, and wide operating temperature (-10C to +70C), the PSAZ-80-P-1 is suitable for deployment in harsh industrial environments-such as manufacturing plants or outdoor installations across different regions, including India.

Q: What is the process for connecting and powering the sensor?

A: Simply connect the 2-wire pre-wired cable to a 12-24V DC power supply. The sensor consumes up to 10 mA, outputs a PNP normally open digital signal, and features an LED indicator for monitoring operational status.

Q: How does this magnetic sensor benefit automation solutions?

A: Its high accuracy, rapid response, robust build, and easy clamp mount facilitate reliable position sensing, reducing downtime and optimizing automated processes in production, fabrication, and export operations.

Q: What certifications and compliance standards does the sensor meet?

A: The product carries CE marking, confirming compliance with international safety and quality standards, making it suitable for use by dealers, exporters, and service providers looking for certified components.

View More Details

Get a Price/Quote Request To Call Back

BTH P20-C Magnetic Sensor

235 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight Approx. 50g

Voltage 10-30V DC

Usage Detecting Magnetic Objects, Position Sensing

Signal Type Digital

Sensor Type Proximity Magnetic Sensor

Sensitivity High Sensitivity to Magnetic Fields

Response Time a 1ms

Resolution Fine Precision

Product Type Magnetic Sensor

Power Consumption < 1W

Output PNP Normally Open (NO)

Operating Temperature -25A C to +70A C

Mounting Type Panel or Surface Mount

Measurement Range 0-10mm Sensing Distance

Material ABS Plastic

Interface 3-wire System

Input 10-30V DC

IP Rating IP67

Function Sensing Magnetic Field

Features Compact size, LED indicator, Robust design

Cable Length 2 meters

Application Industrial Automation, Machinery

Accuracy High

About this product

BTHP20-C MagneticSensor- Dealer, Supplier

Weare dealer and supplier of P20-CMagneticSensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

High Sensitivity and Precision

The BTH P20-C Magnetic Sensor stands out with its high sensitivity and fine precision, ensuring accurate detection of magnetic fields and objects. Its fast response time and narrow sensing range make it suitable for applications that demand quick and reliable position or object sensing. The integrated LED indicator provides instant visual confirmation of sensor status for enhanced operational convenience.

Built for Tough Environments

Engineered with robust ABS housing, the P20-C sensor is IP67 rated, making it highly resistant to dust, water, shock (up to 50G), and vibration (10-55 Hz, 1.5 mm amplitude). Its operating temperature spans -25C to +70C, while storage is safe from -40C to +80C. This resilience suits it for industrial automation, machinery, and environments subject to harsh conditions.

Easy Integration and Versatile Use

Thanks to its compact design, pre-wired 2-meter cable, and 3-wire interface, the P20-C Magnetic Sensor allows for straightforward panel or surface mounting. Its digital PNP NO output can seamlessly interface with modern control systems, making it an excellent choice for manufacturers, automation engineers, and system integrators across various industries.

FAQ's of BTH P20-C Magnetic Sensor:

Q: How does the BTH P20-C Magnetic Sensor operate in industrial automation systems?

A: The BTH P20-C Magnetic Sensor functions by detecting the presence of magnetic fields within a 0-10mm range, providing fast digital output with high sensitivity and fine precision. The sensor's PNP Normally Open (NO) configuration and integrated LED indicator allow seamless integration into control panels, conveyors, and other automated machinery requiring positional accuracy.

Q: What are the primary benefits of using the P20-C Magnetic Sensor for machinery and automation?

A: Key advantages include high reliability, precise magnetic detection, robust IP67 protection, fast response time (1ms), and resistance to shock and vibration. Its compact, durable design enables usage in tight spaces and challenging environments, helping minimize downtime and ensure safe, continuous operation.

Q: When should I choose a pre-wired sensor over other connector types?

A: A pre-wired sensor like the P20-C is ideal when quick and secure installation is required, reducing wiring errors and ensuring firm connectivity. The attached 2-meter cable simplifies mounting in inaccessible areas or where movement and vibration might loosen other connector types.

Q: Where can the BTH P20-C Magnetic Sensor be mounted for optimal performance?

A: This sensor can be easily mounted on panels or surfaces near the magnetic object it needs to detect. Its IP67 protection means it performs reliably in damp, dusty, or vibration-prone settings commonly found in manufacturing plants and industrial machinery.

Q: What is the process for wiring the P20-C Magnetic Sensor into a control system?

A: The sensor features a pre-wired 3-wire configuration: connect the brown wire to +V (10-30V DC), the blue wire to 0V (ground), and the black wire as the output signal. Verify polarity and follow proper electrical safety protocols during installation.

Q: How is the sensor's accuracy and precision maintained in fluctuating temperature or vibration conditions?

A: The device's ABS construction, IP67 rating, and high vibration and shock resistance ensure stable performance across varying temperatures (-25C to +70C) and mechanical stresses, preserving accuracy in dynamic industrial settings.

Q: What applications benefit most from the fine resolution and high sensitivity of the P20-C sensor?

A: Applications that demand rapid, precise detection-such as position sensing, robotic arms, assembly lines, and presence verification-greatly benefit from the sensor's fine resolution, fast response, and reliable output.

View More Details

Get a Price/Quote Request To Call Back

BTH PSAZ-75P Magnetic Sensor

300 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight Approx. 25g

Voltage 10-30V DC

Usage Industrial Automation, Position Sensing

Signal Type Digital

Sensor Type Reed Magnetic Sensor

Sensitivity Standard Magnetic Sensitivity

Response Time <1 ms

Resolution High

Product Type Magnetic Sensor

Power Consumption < 10 mA

Output PNP Normally Open (NO)

Operating Temperature -20A C to +60A C

Mounting Type Surface Mount / Screw Mount

Measurement Range Up to 75 mm

Material ABS Plastic, Electronic Components

Interface 3-wire

Input DC Supply

IP Rating IP67

Function Detects Magnetic Field/Position

Features Short-circuit Protection, LED Indicator

Cable Length 2 meters

Application Automation Systems, Door Sensing, Machine Safety

Accuracy A 1%

About this product

BTHPSAZ-75P MagneticSensor- Dealer, Supplier

Weare dealer and supplier of PSAZ-75PMagneticSensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Reliable Position Sensing for Automation Systems

The BTH PSAZ-75P Magnetic Sensor is crafted for seamless integration into industrial automation processes. Its sensitivity and high-resolution sensing capabilities deliver accurate position detection up to 75 mm. Combined with a rugged IP67 ABS housing, it provides dependable performance in harsh factory settings, supporting applications such as safety interlocks, object detection, and automated door monitoring.

Durable Design with Enhanced Longevity

Designed to withstand challenging operational environments, the PSAZ-75P endures vibration (10-55 Hz, 1.5 mm amplitude) and shock (up to 50G). Its mechanical life exceeds 10 million operations, ensuring minimal downtime and long-term reliability, while the built-in red LED indicator gives operators immediate visual feedback on power and status, improving system diagnostics.

FAQ's of BTH PSAZ-75P Magnetic Sensor:

Q: How is the BTH PSAZ-75P Magnetic Sensor installed in automation systems?

A: The sensor is designed for surface or screw mounting, making installation simple in a variety of industrial setups. Its pre-wired, 2-meter PVC-insulated cable allows easy connection to control systems without the need for additional wiring accessories.

Q: What applications are ideal for the PSAZ-75P Magnetic Sensor?

A: This sensor is perfect for industrial automation, machine safety interlocks, automated door position sensing, and other scenarios requiring efficient magnetic field or position detection, particularly where durability and accuracy are essential.

Q: When should the sensor's output be used for process control?

A: The digital PNP normally open (NO) output should be used when you require a swift and accurate indication of magnetic field or position presence within a 75 mm range, such as triggering actuators, alarms, or machine safety circuits.

Q: Where can the sensor be safely deployed given its environmental ratings?

A: With its IP67 rating and operational temperature range of -20C to +60C, the sensor can be installed in wet, dusty, or industrial environments commonly found in factories or warehouses.

Q: What are the main benefits of using this magnetic sensor?

A: It offers high accuracy (1%), rapid response (<1 ms), robust shock and vibration resistance, low power consumption (<10 mA), long mechanical life, and visual status indication, ensuring efficient and reliable operation in demanding automation contexts.

Q: How does the red LED indicator support users?

A: The integrated red LED provides an immediate visual indication of power and operating status, enabling quick diagnostics and reducing troubleshooting time during regular operation or maintenance.

Q: What is the typical process for integrating the sensor into a control system?

A: Simply connect the 3-wire PNP NO output to your existing control circuit, mount the sensor near the target position or magnetic field, and utilize its digital signal output for direct integration into programmable logic controllers or safety relay modules.

View More Details

Get a Price/Quote Request To Call Back

BTH BIS-17WK Inductive Metal Face Sensor

560 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight 115 g

Voltage 10-30 V DC

Usage Industrial Automation

Signal Type Digital

Sensor Type Proximity Sensor

Sensitivity Adjustable

Response Time < 2 ms

Resolution Standard

Product Type Inductive Metal Face Sensor

Power Consumption Low

Output PNP, NO (Normally Open)

Operating Temperature -25A C to +70A C

Mounting Type Flush Mount

Measurement Range 0-8 mm (Sensing Distance)

Material Metal

Interface 3-Wire

Input DC Supply

IP Rating IP67

Function Object Detection

Features Short Circuit Protection, Polarity Protection

Cable Length 2 Meter

Application Metal Detection

Accuracy High Precision

About this product

BTHBIS-17WK Inductive Metal Face Sensor-Dealer, Supplier

Weare dealer and supplier of BTH BIS-17WK Inductive Metal Face Sensorin India, Mumbai, Delhi, Ahmedabad, Chennai, Kolkata, Pune, Nashik,Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot,Gandhidham, Morbi, Indore, Bhopal, Faridabad, Ghaziabad, Noida,Gurgaon, Coimbatore, Bangalore, Hyderabad, Kanpur, Goa,Visakhapatnam, Cochin, Ernakulam, Ludhiana, Chandigarh, Baddi,Dehradun, Sangli, Satara, Ichalkarnji, Solapur, Kupwad, Kolhapur,Pimpri, Chinchwad, Jalgaon, Surat, Baroda, Morbi, UAE, Bangladesh,Nepal, Bhutan, Dubai, Saudi Arabia, United Arab Emirates, Abu Dhabi,Bahrain, Qatar, Muscat, Oman, Sri Lanaka, South Africa, Myanmar,Thailand, Vietnam, Jakarta, Indonesia.

Weare dealer, supplier of various manufacture of BTH Induction motor,BTH Rotary Encoder, BTH Encoder, BTH Pressure Sensor, BTH Process &Sensor Controller, BTH Reed Sensor, BTH Inductive Sensor, BTHCapacitive Sensor, BTH Sensor Cable, BTH Proximity sensor, BTH Photosensor, BTH Photoelectric Sensor, BTH FiberOptic Sensor, BTH Liquid Sensor, BTH Level Switches, BTH MagneticFloat Switches, BTH SMPS, BTH SSR, BTH TPR, BTH DC Supply, BTHSignal.inductivesensor,proximity sensors,inductiveproximity sensor,inductiveproximity switches,inductiveswitches.

Reliable and Precise Detection

Designed for industrial automation, the BIS-17WK ensures precise detection of metallic objects with a high repeatability of 0.01 mm. Its advanced sensing technology and robust housing support reliable operation across various environments, from manufacturing floors to process lines.

Built to Endure Harsh Environments

Constructed with a nickel-plated brass body and rated at IP67, the sensor resists dust, water, and physical impact. It operates efficiently in temperatures ranging from -25C to +70C, making it suitable for diverse industrial applications.

Simple Integration and Operation

The BIS-17WK integrates effortlessly into automation systems with its standard M18 dimension and flush-mount capability. The 2-meter cable end and 3-wire interface enable straightforward electrical connection, while the LED indicator ensures quick status verification for users.

FAQ's of BTH BIS-17WK Inductive Metal Face Sensor:

Q: How does the BIS-17WK Inductive Metal Face Sensor detect objects?

A: The BIS-17WK utilizes inductive sensing technology to detect metallic objects within a 0-8 mm range. When a metal item enters the sensor's magnetic field, it alters the field, triggering the sensor's digital output for object detection.

Q: What makes this sensor suitable for industrial environments?

A: Its nickel-plated brass housing, IP67 protection, and broad operating temperature range enable the sensor to withstand exposure to dust, water, vibrations, and extreme temperatures common in industrial settings. It also comes equipped with short circuit and polarity protection for operational safety.

Q: When should I use the BIS-17WK sensor?

A: You should use the BIS-17WK in applications requiring accurate, reliable detection of metal objects, such as assembly automation, packaging lines, or equipment monitoring in harsh, high-demand environments.

Q: Where can the BIS-17WK sensor be installed?

A: This sensor is designed for flush mounting into machinery or equipment, making it ideal for integration in control panels, conveyor systems, or anywhere space and protection against contaminants are considerations.

Q: What are the benefits of the LED indicator on this sensor?

A: The integrated LED provides immediate, visual status updates of the sensor's operation, allowing for quick diagnostics and ensuring efficient workflow and maintenance processes.

Q: How is the BIS-17WK connected to control systems?

A: It features a 3-wire interface and a 2-meter cable end for easy connection. The output is PNP, Normally Open, and it operates with a 10-30 V DC power supply, making it compatible with standard industrial controllers.

Q: What is the process for adjusting the sensor's sensitivity?

A: The BIS-17WK offers adjustable sensitivity, typically configured by turning a built-in potentiometer or following specific instructions provided in the product's manual to suit various metal objects and distances within the 0-8 mm sensing range.

View More Details

Get a Price/Quote Request To Call Back

BTH BIS-17PN Inductive Metal Face Sensor

520 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight Approx. 100g

Voltage 10-30V DC

Usage Industrial Automation

Signal Type Digital

Sensor Type Inductive Proximity Sensor

Sensitivity Adjustable

Response Time <2 ms

Resolution Standard

Product Type Inductive Metal Face Sensor

Power Consumption <10 mA

Output PNP Normally Open (NO)

Operating Temperature -25A C to +70A C

Mounting Type Flush/Embeddable

Measurement Range 17mm Sensing Distance

Material Metal

Interface 3-wire DC

Input 10-30V DC

IP Rating IP67

Function Object Detection

Features Metal face, Vibration resistant, Short-circuit protection

Cable Length 2 meters

Application Position Sensing, Metal Detection

Accuracy High

About this product

BTHBIS-17PN Inductive Metal Face Sensor-Dealer, Supplier

Weare dealer and supplier of BTH BIS-17PN Inductive Metal Face Sensorin India, Mumbai, Delhi, Ahmedabad, Chennai, Kolkata, Pune, Nashik,Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot,Gandhidham, Morbi, Indore, Bhopal, Faridabad, Ghaziabad, Noida,Gurgaon, Coimbatore, Bangalore, Hyderabad, Kanpur, Goa,Visakhapatnam, Cochin, Ernakulam, Ludhiana, Chandigarh, Baddi,Dehradun, Sangli, Satara, Ichalkarnji, Solapur, Kupwad, Kolhapur,Pimpri, Chinchwad, Jalgaon, Surat, Baroda, Morbi, UAE, Bangladesh,Nepal, Bhutan, Dubai, Saudi Arabia, United Arab Emirates, Abu Dhabi,Bahrain, Qatar, Muscat, Oman, Sri Lanaka, South Africa, Myanmar,Thailand, Vietnam, Jakarta, Indonesia.

Reliable Performance in Harsh Environments

Engineered with a nickel-plated brass housing and an IP67 rating, the BTH BIS-17PN Inductive Metal Face Sensor is highly resistant to water, dust, and physical shocks. This robust construction ensures consistent performance, even in challenging industrial settings, making it a preferred choice for factories and automation lines. Its vibration resistance further enhances its longevity and operational reliability under extreme conditions.

Efficient Object Detection and Position Sensing

With a standard 17mm sensing range and a fast response time under 2ms, this sensor guarantees high accuracy for detecting metal objects. The adjustable sensitivity and high switching frequency of 500 Hz make it suitable for dynamic automation processes, ensuring rapid and precise feedback essential for position sensing and metal detection in diverse industrial applications.

Advanced Safety and Protection Features

Incorporating advanced safety measures, the BTH BIS-17PN includes short-circuit and overload protection, as well as polarity protection to safeguard against incorrect wiring. The built-in LED status indicator simplifies diagnostics and monitoring, reducing downtime during maintenance while ensuring stable system integration and operation.

FAQ's of BTH BIS-17PN Inductive Metal Face Sensor:

Q: How does the BTH BIS-17PN inductive metal face sensor detect objects?

A: The BTH BIS-17PN sensor uses inductive technology to sense metal objects within a 17mm range. It emits an electromagnetic field, and when a metal target enters this field, the sensor outputs a digital signal, making it ideal for position sensing and object detection in automation systems.

Q: What are the main benefits of using this sensor in industrial automation?

A: This sensor provides reliable metal detection with high accuracy, rapid switching frequency (500 Hz), and robust protection features such as short-circuit, overload, and polarity protection. Combined with its shock and vibration resistance, it ensures minimal downtime and long service life in demanding industrial environments.

Q: When should I choose this sensor for my application?

A: Select the BTH BIS-17PN when you need precise detection of metal objects, stable operation in harsh environments, and the assurance of IP67 protection. It is perfect for manufacturing, assembly lines, or any automation task requiring reliable position sensing and object detection.

Q: Where can the BTH BIS-17PN sensor be installed?

A: Thanks to its flush/embeddable mounting and durable metal housing, this sensor can be installed directly in machinery, conveyor systems, or process automation lines. Its IP67 rating and robust design allow for use in areas exposed to water, dust, or vibration.

Q: What is the process for connecting and operating this sensor?

A: The sensor connects with a 2-meter, 3-wire DC cable for easy integration into control systems. Simply secure it using its M18 threaded mounting, connect to a 10-30V DC power source, and observe the LED status indicator for operational feedback. Its normally open PNP output delivers fast digital signals to your PLC or control circuits.

Q: How can I adjust the detection sensitivity?

A: The BTH BIS-17PN features adjustable sensitivity, enabling you to fine-tune its response for different metallic objects or installation scenarios. Refer to the manufacturer's guidelines or adjustment screw typically located on the sensor for optimal settings.

Q: What safety features are incorporated in this sensor?

A: This sensor includes advanced safety measures like short-circuit and overload protection, polarity protection, and a solid-state output. These features safeguard both the sensor and connected systems, providing reliable, worry-free operation over extended periods.

View More Details

Get a Price/Quote Request To Call Back

BTH BIS-17NN Inductive Magnetic Sensor

520 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight Approx 50 g

Voltage 10-30 V DC

Usage Non-contact Sensing

Signal Type Digital

Sensor Type Inductive Magnetic

Sensitivity High Sensitivity

Response Time <10 ms

Resolution Fine Resolution

Product Type Inductive Magnetic Sensor

Power Consumption Low Power Consumption

Output NPN, NO+NC

Operating Temperature -25A C to +70A C

Mounting Type Flush/Panel Mounting

Measurement Range 17 mm

Material ABS Body

Interface 3-wire

Input 10-30 V DC

IP Rating IP67

Function Detects Magnetic or Metallic Objects

Features Reverse Polarity Protection, High Switching Frequency

Cable Length 2 meters

Application Industrial Automation, Position Sensing, Proximity Detection

Accuracy High Accuracy

About this product

BTH BIS-17NN Inductive Magnetic Sensor- Dealer, Supplier

Weare dealer and supplier of BTH BIS-17NN Inductive Magnetic Sensorin India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Durable and Reliable Design

Constructed with a nickel-plated brass housing and an ABS body, the BTH BIS-17NN sensor is built to withstand challenging industrial environments. Its IP67 rating ensures excellent resistance to dust, moisture, and water ingress, providing reliable operation even under harsh operating conditions.

Precise Non-Contact Sensing

The BIS-17NN sensor is engineered for accurate, non-contact detection of magnetic or metallic objects. With a 17 mm sensing range, high sensitivity, and fine resolution, it is ideal for position sensing, proximity detection, and industrial automation processes, delivering consistently high accuracy.

Enhanced Safety and Performance

Featuring built-in short circuit and reverse polarity protection, this sensor delivers safe, stable performance in a wide range of applications. Its LED status indicator provides quick visual feedback, while robust electrical parameters enable integration with modern automation systems.

FAQ's of BTH BIS-17NN Inductive Magnetic Sensor:

Q: How does the BTH BIS-17NN Inductive Magnetic Sensor operate in industrial environments?

A: The BTH BIS-17NN sensor operates reliably in industrial settings, detecting magnetic or metallic objects without physical contact. Its IP67-rated nickel-plated brass and ABS construction provides resistance against dust, water, and harsh chemicals for continuous use.

Q: What benefits does the high switching frequency offer for automation applications?

A: With a switching frequency of up to 500 Hz and a response time under 10 ms, the sensor delivers rapid detection suitable for high-speed automation, enabling precise monitoring of fast-moving equipment and processes.

Q: When should the BIS-17NN sensor be used for position or proximity detection?

A: This sensor is best utilized in scenarios requiring precise position or proximity detection, such as industrial automation, machine safety systems, and assembly lines where accurate, real-time feedback is essential.

Q: Where can the BIS-17NN sensor be mounted, and what is the recommended installation process?

A: The BIS-17NN supports flush or panel mounting, typically near the area where object detection is needed. Installation involves securing the sensor with appropriate fixtures and connecting the 2-meter pre-wired cable to a compatible 10-30 V DC power supply and control circuit.

Q: What usage precautions are important when applying this sensor in humid conditions?

A: The sensor is designed to function at an operating humidity range of 35%-85% RH. Ensure that moisture does not accumulate around electrical connections and that the device is installed according to its IP67 protection guidelines.

Q: What key features contribute to the long service life and efficiency of the BIS-17NN sensor?

A: Key features include short circuit and reverse polarity protection, robust housing, low power consumption, and high switching frequency, all of which contribute to sensor longevity and efficient performance.

View More Details

Get a Price/Quote Request To Call Back

BTH BIT6.5-NN2F Proximity Sensor

900 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight Approx. 45g

Voltage 10-30V DC

Usage Industrial Automation, Machine Position Sensing

Signal Type Digital

Sensor Type Inductive Proximity

Sensitivity High

Response Time <2 ms

Resolution High

Product Type Proximity Sensor

Power Consumption a 15mA

Output NPN (Normally Open)

Operating Temperature -25A C to +70A C

Mounting Type Flush mounting

Measurement Range 6.5 mm

Material Plastic Body

Interface 3-Wire

Input DC

IP Rating IP67

Function Detects Ferrous and Non-Ferrous Objects

Features Short Circuit Protection, Reverse Polarity Protection, LED Indication

Cable Length 2 Meters

Application Automated Systems, Conveyor Detection

Accuracy A 0.5 mm

About this product

BTH BIT6.5-NN2F Proximity Sensor- Dealer, Supplier

Weare dealer and supplier of BTH BIT6.5-NN2F Proximity Sensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Precision Sensing for Industrial Demands

The BTH BIT6.5-NN2F Proximity Sensor delivers high-accuracy position sensing in complicated industrial setups. With an accuracy of 0.5 mm, high sensitivity, and repeatability of less than 1%, it meets the stringent requirements of automated machinery and conveyor applications. The sensors quick response time and high switching frequency ensure no interruption in detection, even at high speeds.

Designed for Harsh Environments

Encased in a durable plastic housing, the BIT6.5-NN2F stands up to demanding environments with an IP67 ingress protection rating. It functions reliably within a broad temperature range of -25C to +70C and withstands vibrations and shocks typical in industrial plants, making it a dependable sensor for long-term use.

User-Friendly Features and Integration

Installation is straightforward with flush mounting and a two-meter PVC cable. The three-wire interface supports easy integration, while features such as LED indication, short circuit, and reverse polarity protection enhance user confidence and simplify maintenance. Operating on NPN (Normally Open) output, it effortlessly complements various industrial control systems.

FAQs of BTH BIT6.5-NN2F Proximity Sensor:

Q: How does the BTH BIT6.5-NN2F Proximity Sensor detect objects?

A: This sensor employs inductive technology, meaning it generates an electromagnetic field to detect both ferrous and non-ferrous metallic objects within a 6.5 mm range. It has high sensitivity and delivers accurate digital signals for automated control systems.

Q: What environments are suitable for using the BTH BIT6.5-NN2F sensor?

A: Its IP67 rating, vibration and shock resistance, and wide operating temperature range (-25C to +70C) make it ideal for industrial automation, machine positioning, and conveyor operations in harsh or demanding settings.

Q: When should I choose this sensor for industrial projects?

A: Opt for the BIT6.5-NN2F when you need fast, accurate proximity detection of metal objects, high noise immunity, and reliable operation under tough ambient conditionsespecially in automated processing and material handling equipment.

Q: Where can the BTH BIT6.5-NN2F be mounted?

A: This sensor supports flush mounting, letting it be installed directly into machine frames or conveyor systems, ensuring precise alignment and protection from accidental damage or misalignment.

Q: What is the process for integrating this sensor with my automated system?

A: Installation involves mounting the sensor at the desired location, securing the sensor head, and connecting the 3-wire PVC cable (2 meters) to your DC power supply (10-30V DC) and NPN-compatible digital input. LED indication assists in confirming operation.

Q: How does the sensors short circuit and reverse polarity protection benefit users?

A: These features prevent damage to the sensor and connected equipment in case of wiring errors or power issues, enhancing overall system safety and reducing maintenance needs.

Q: What are the key advantages of using this proximity sensor in industry?

A: High accuracy (0.5 mm), rapid response time (<2 ms), low power consumption, robust construction, and safety features make it dependable for automated systems requiring precise metal object detection and minimal downtime.

View More Details

Get a Price/Quote Request To Call Back

BTH PSAZ-100P Magnetic Sensor

325 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight 50g

Voltage 12-24V DC

Usage Industrial Automation, Security Systems

Signal Type Digital

Sensor Type Proximity Magnetic Sensor

Sensitivity High sensitivity for magnetic sensing

Response Time <1 ms

Resolution 0.1 mm

Product Type Magnetic Sensor

Power Consumption <15mA

Output PNP Normally Open (NO)

Operating Temperature -10A C to +60A C

Mounting Type Surface Mount

Measurement Range 0-100 mm

Material ABS Plastic

Interface 2-wire

Input 100V AC/DC

IP Rating IP67

Function Detects Magnetic Field Presence

Features LED Indicator, Compact Design, Shock Resistant

Cable Length 2 m

Application Position Sensing, Door Sensing

Accuracy A 1 mm

About this product

BTHPSAZ-100P MagneticSensor- Dealer, Supplier

Weare dealer and supplier of PSAZ-100PMagneticSensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Features Designed for High Reliability

BTH PSAZ-100P offers advanced features such as high sensitivity, fast 1000 Hz switching, and a visible LED indicator. Its surface-mountable, compact design ensures easy installation in tight spaces, while the IP67-rated ABS plastic housing provides superior dust and water resistance. The sensor's robust build withstands high vibration and temperature fluctuations, ensuring stable performance in demanding industrial settings.

Applications in Automation and Security

This sensor excels in position and door sensing applications within industrial automation systems and security infrastructure. Its digital PNP Normally Open output enables integration with controllers, alarms, and automation units seamlessly. The 2-meter cable and two-wire interface make wiring straightforward for a wide range of use cases, including OEM manufacturing, security solutions, and access control.

Benefits for Industry Professionals

With its CE certification, high accuracy (1 mm), and low power consumption (<15mA), the BTH PSAZ-100P supports energy-efficient and reliable operations. Its shock resistance and high protection ratings reduce maintenance needs, while versatile mounting options accommodate various installation requirements for dealers, exporters, and other supply chain partners.

FAQ's of BTH PSAZ-100P Magnetic Sensor:

Q: How do I install the BTH PSAZ-100P Magnetic Sensor in my automation system?

A: Simply surface-mount the sensor using its compact design, connect the two-wire interface to your control system with a 12-24V DC supply, and position it within the 0-100 mm measurement range of the target magnet to achieve optimal sensing.

Q: What are the advantages of using a reed switch in this magnetic sensor?

A: The reed switch provides high accuracy (1 mm), rapid switching speed (up to 1000 Hz), and reliable digital output, making it well-suited for precise position and door sensing in industrial and security applications.

Q: When should I choose this sensor over other types for my project?

A: Select the BTH PSAZ-100P when you require robust environmental protection (IP67 rating), high vibration resistance, fast response (<1 ms), and consistent performance in temperatures from -10C to +60C, especially for automation or security implementations.

Q: Where is this magnetic sensor commonly used?

A: It is widely implemented in industrial automation for position and door sensing, as well as security systems requiring reliable detection of magnetic field presence. The sensor is suitable for use by manufacturers, integrators, and service providers across India.

Q: What is the process for integrating this sensor into an existing security system?

A: After mounting, connect the sensor's PNP Normally Open output to your controller or alarm system. Use the LED indicator to confirm proper operation, and ensure it is positioned within 100 mm of the activating magnet for accurate detection.

Q: How does the sensor's IP67 rating benefit its operation?

A: The IP67 rating ensures complete protection against dust ingress and temporary water immersion, enabling the sensor to operate reliably in harsh industrial or outdoor environments without risk of failure.

Q: What are the energy consumption and voltage requirements for this sensor?

A: The BTH PSAZ-100P operates efficiently with a low power consumption of less than 15mA and supports input voltages from 12 to 24V DC, making it suitable for most industrial control and security systems.

View More Details

Get a Price/Quote Request To Call Back

BTH BTC33-V Magnetic Sensor

2400 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight Approx. 50 grams

Voltage 10-30V DC

Usage Position detection/automation systems

Signal Type Digital

Sensor Type Magnetic Proximity

Sensitivity High sensitivity

Response Time <1 ms

Resolution Precise detection

Product Type Magnetic Sensor

Power Consumption <15 mA

Output PNP/NPN

Operating Temperature -25A C to +70A C

Mounting Type Surface mount

Measurement Range Up to 10mm

Material ABS Plastic

Interface 3-wire

Input DC 24V

IP Rating IP67

Function Sensing magnet position

Features LED indication, Compact size, Shock resistant

Cable Length 2 meters

Application Industrial automation, Security systems

Accuracy High

About this product

BTHBTC33-V MagneticSensor- Dealer, Supplier

Weare dealer and supplier of BTC33-VMagneticSensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Precision Sensing for Industrial Automation

The BTH BTC33-V Magnetic Sensor offers accurate position detection crucial for automation systems. Its high-resolution capability ensures reliable performance with swift response times, making it an optimal choice for processes that require precise and repeatable detection. Integrated LED indication provides instant visual feedback during operation.

Durability and Safety Features

Built from reinforced ABS plastic, the BTC33-V delivers excellent durability against mechanical shocks and industrial vibrations. The device is further protected with polarity and reverse connection features. Suitable for tough environments, its IP67 enclosure prevents dust and moisture ingress, enhancing operational safety and longevity.

Flexible Installation and Power

Accommodating various industrial setups, the sensor includes a 2-meter cable and utilizes a 3-wire interface for easy integration. Operating on a wide voltage range (10-30V DC) and consuming less than 15 mA, it ensures energy efficiency. Surface mounting allows straightforward installation even in compact spaces.

FAQ's of BTH BTC33-V Magnetic Sensor:

Q: How is the BTH BTC33-V Magnetic Sensor installed?

A: The BTC33-V sensor is designed for surface mounting, using its compact enclosure and included 2-meter cable for flexible placement in industrial environments. The 3-wire interface simplifies connection to automation systems.

Q: What applications can benefit from using this magnetic proximity sensor?

A: This sensor is ideal for industrial automation and security systems, functioning as a position detector with high accuracy and rapid response, making it suitable for precise process control and equipment monitoring.

Q: When should this sensor be selected over other position sensors?

A: Choose the BTC33-V for applications requiring enhanced shock and vibration resistance, precise detection up to 10mm, fast switching (up to 1000 Hz), and reliable operation in harsh conditions, as evidenced by its IP67 rating and robust construction.

Q: Where can the BTH BTC33-V Magnetic Sensor be sourced in India?

A: The sensor is available through a range of dealers, distributors, exporters, importers, manufacturers, producers, retailers, service providers, suppliers, traders, and wholesalers across India, catering to diverse industrial needs.

Q: What is the process for maintaining this magnetic sensor?

A: Maintenance typically involves cleaning the sensor housing, checking cable integrity, and periodically verifying LED operation and output signals. Its IP67 rating and shock-resistant build minimize regular maintenance requirements.

Q: How does using this sensor improve automation systems?

A: The BTC33-V enhances automation by providing accurate digital position feedback, swift response times (<1 ms), and stable operation under industrial stresses, which collectively contribute to improved reliability and productivity.

Q: What are the main benefits of the BTC33-V's reinforced ABS plastic enclosure?

A: The reinforced ABS plastic enclosure offers robust protection against physical impacts and vibrations, ensuring long-term reliability for the sensor even in demanding industrial applications.

View More Details

Get a Price/Quote Request To Call Back

BTH BI-52S-200-NU Magnetic Sensor

5110 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight Approx. 50g

Voltage 12-24V DC

Usage Industrial Automation, Position Sensing

Signal Type Digital

Sensor Type Proximity Magnetic Sensor

Sensitivity High Sensitivity

Response Time Fast (< 1ms)

Resolution Precise Switching

Product Type Magnetic Sensor

Power Consumption Low

Output PNP Normally Open (NO)

Operating Temperature -25A C to +70A C

Mounting Type Flush Mount (Threaded Barrel)

Measurement Range Sensing distance up to 15mm

Material Metal Body

Interface 3-wire type

Input 12-24V DC

IP Rating IP67

Function Detection of Magnetic Field

Features LED Indicator, Compact Design, Robust Metal Housing

Cable Length 2 meters

Application Detecting Magnetic Targets, Limit Switch, Automation

Accuracy High

About this product

BTHBI-52S-200-NUMagneticSensor- Dealer, Supplier

Weare dealer and supplier of BTHBI-38S-200-PUMagneticSensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Advanced Detection Capabilities

This magnetic sensor provides high accuracy and resolution for detecting magnetic fields, making it ideal for position sensing, automation, and positioning systems. The sensor's high switching frequency and quick response enhance performance in dynamic industrial environments.

Robust and Reliable Construction

Protected by a nickel-plated brass enclosure and rated IP67, the BI-52S-200-NU withstands dust, moisture, and heavy-duty industrial conditions. Its metal body resists impact and corrosion, ensuring long-term reliability for various industrial uses.

Effortless Integration and Installation

Featuring a flush mount threaded barrel and 2-meter cable, installation is straightforward in space-constrained setups. The 3-wire interface and LED indicator simplify connection and status monitoring, while short-circuit and polarity protection safeguards your automation systems.

FAQ's of BTH BI-52S-200-NU Magnetic Sensor:

Q: How does the BI-52S-200-NU Magnetic Sensor detect magnetic fields?

A: The sensor utilizes high-sensitivity magnetic technology to detect the presence or movement of magnetic targets within a sensing distance of up to 15mm, enabling precise position sensing and automation control.

Q: What industrial applications is the BI-52S-200-NU suitable for?

A: It is ideal for industrial automation, limit switch functions, detecting magnetic targets, and position sensing tasks due to its fast response, high resolution, and reliable output.

Q: When should I use the BI-52S-200-NU Magnetic Sensor in my process?

A: Deploy this sensor whenever you require accurate detection of magnetic fields in automated machinery, assembly lines, or position monitoring, especially in environments demanding robust performance.

Q: Where can the BI-52S-200-NU Magnetic Sensor be installed?

A: Designed for flush mount installation, the sensor fits securely in threaded M18 housings. Its IP67 rating allows placement in moist, dusty, or industrial environments across factories and automation setups.

Q: What benefits does short circuit and polarity protection provide?

A: Short circuit and polarity protection ensure stable operation, protecting both the sensor and associated control equipment from electrical faults and incorrect wiring.

Q: How do I connect the sensor to my control system?

A: With its 3-wire type cable and PNP normally open output, the sensor easily interfaces with most industrial control systems operating at 12-24V DC. The integrated LED indicator provides quick status feedback.

Q: What makes this sensor advantageous for industrial automation in India?

A: The BI-52S-200-NU offers compact design, robust build, high sensitivity, and low power consumption, making it suitable for demanding conditions while providing reliable and precise switching in automation systems.

View More Details

Get a Price/Quote Request To Call Back

BTH BY-NT100C Magnetic Sensor

2600 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight Approx. 30g

Voltage 10-30V DC

Usage Automation Systems, Safety Devices

Signal Type Digital

Sensor Type Contactless Magnetic Proximity Sensor

Sensitivity High

Response Time <1 ms

Resolution High

Product Type Magnetic Sensor

Power Consumption a 10 mA

Output PNP/NPN, Normally Open (NO)

Operating Temperature -25A C to +70A C

Mounting Type Flush Mount

Measurement Range 0-10 mm

Material ABS Plastic

Interface 3-wire

Input DC Signal

IP Rating IP67

Function Sensing Magnetic Field Presence

Features Compact Design, LED Indicator, Reverse Polarity Protection

Cable Length 2 m

Application Industrial Automation, Position Sensing

Accuracy A 1 mm

About this product

BTHBY-NT100C MagneticSensor- Dealer, Supplier

Weare dealer and supplier of BTHBY-NT100C MagneticSensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Precision Magnetic Sensing for Automation

The BY-NT100C Magnetic Sensor delivers accurate and rapid magnetic field detection with a 1 mm accuracy and high resolution. Engineered for industrial environments, it is robust enough to withstand shock (30G for 11 ms) and vibration, making it perfect for automated machinery, conveyor systems, and safety interlocks. Its lifecycle exceeds 10 million operations, ensuring longevity and reliable long-term performance in demanding conditions.

Advanced Safety and Protection Features

Safety is paramount with the BY-NT100C, thanks to its built-in short-circuit, overload, and reverse polarity protections. The sensor's durable ABS plastic housing and oil-resistant PVC wiring provide further insulation and resilience. The integrated LED indicator allows for easy operation monitoring. Its IP67 rating means it can perform optimally even in dusty or moist environments found across industrial facilities.

FAQ's of BTH BY-NT100C Magnetic Sensor:

Q: How is the BTH BY-NT100C Magnetic Sensor installed and connected in automation systems?

A: The sensor supports flush mounting and is connected using a 3-wire interface: brown for DC+, blue for DC-, and black for output. Cable length is 2 meters, allowing flexibility in installation. Simply mount the sensor at the desired sensing point and connect the wiring as per your control system's input specifications.

Q: What benefits does the high resolution and rapid response time of this sensor offer for industrial applications?

A: With a high resolution and response time of less than 1 ms, the sensor ensures precise and near-instant detection of magnetic fields. This significantly enhances accuracy and efficiency in position sensing and safety applications, minimizing delays or errors in automated processes.

Q: When should I choose the BY-NT100C Magnetic Sensor over other proximity sensors?

A: Choose the BY-NT100C when your application requires non-contact, high-accuracy position sensing in harsh environments. Its robust build, high insulation resistance, and IP67 protection make it ideal for automation, safety devices, and anywhere high durability and reliability are essential.

Q: Where can this magnetic sensor be effectively used within industrial facilities?

A: It is best suited for use in manufacturing lines, robotic arms, conveyor systems, safety interlocks, and other places needing precise position or presence detection. Its oil-resistant, water-resistant, and vibration-resistant properties make it versatile for multiple industrial settings.

Q: What process does the BY-NT100C use to detect magnetic fields?

A: The sensor operates by detecting changes in the magnetic field within its specified 0-10 mm range. It triggers a digital output signal when a magnetic target is present, making it suitable for contactless sensing in dynamic environments.

Q: How does the sensor ensure safety and longevity in operation?

A: The BY-NT100C features short-circuit, overload, and reverse polarity protection, and its rugged ABS housing shields against environmental hazards. With a lifecycle rated to at least 10 million operations and IP67 ingress protection, it offers lasting performance and reduced maintenance.

View More Details

Get a Price/Quote Request To Call Back

BTH PSAZ-25-1/2-P Magnetic Sensor

250 INR/Piece

Minimum Order Quantity : 1 Pieces

Wireless No

Weight Approx. 50 g

Voltage 12-24V DC

Usage Pneumatic Cylinder Sensing

Signal Type Digital

Sensor Type Reed Switch / Magnetic Proximity

Sensitivity High

Response Time a 1 ms

Resolution High

Product Type Magnetic Sensor

Power Consumption <10 mA

Output PNP NO (Normally Open)

Operating Temperature -20A C to +70A C

Mounting Type Clamp-on / Slot Mount

Measurement Range Up to 25 mm Cylinder Bore

Material ABS Plastic Housing

Interface 3-wire

Input 12-24V DC

IP Rating IP67

Function Position Detection

Features Compact design, Easy installation, LED indicator

Cable Length 2 Meter

Application Industrial Automation, Pneumatics

Accuracy A 1 mm

About this product

BTHPSAZ-25-1/2-P MagneticSensor- Dealer, Supplier

Weare dealer and supplier of PSAZ-25-1/2-PMagneticSensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Reliable Position Detection for Pneumatic Cylinders

The BTH PSAZ-25-1/2-P Magnetic Sensor delivers precise position detection, specifically designed for standard T-slot pneumatic cylinders. Its 1 mm accuracy and high-resolution sensing ensure optimal performance in automation systems requiring accurate cylinder movement monitoring.

Durable and Easy to Install

Featuring an IP67 ABS plastic housing, the sensor withstands harsh industrial settings with strong vibration and shock resistance. Its compact structure, clamp-on/slot mount design, and pre-wired 2-meter cable allow for quick, hassle-free installation and maintenance.

Efficient Performance with LED Indicator

Equipped with a clear LED indicator, this sensor provides immediate visual feedback of operational status. Its digital PNP NO output, low power consumption, and quick response (1 ms) support efficient, reliable integration into control systems for industrial automation and pneumatics.

FAQ's of BTH PSAZ-25-1/2-P Magnetic Sensor:

Q: How do I install the BTH PSAZ-25-1/2-P Magnetic Sensor on my pneumatic cylinder?

A: Mount the sensor directly into the T-slot of any standard pneumatic cylinder using the provided clamp-on or slot mount. Once in place, connect the pre-wired 2-meter PVC cable to your control system, ensuring you observe correct 3-wire PNP NO wiring for 12-24V DC input.

Q: What operational environments is this sensor suited for?

A: The sensor is built to work reliably in industrial environments, withstanding shock up to 30G, vibrations from 10-55 Hz (1.5 mm amplitude), humidity levels from 35% to 85% RH, and temperatures between -20C and +70C during operation and -25C to +80C in storage.

Q: Where can this magnetic sensor be used within industrial automation?

A: It is ideal for applications requiring precise pneumatic cylinder position sensing, including packaging machines, assembly lines, robotics, and other automated processes where monitoring cylinder movement is critical.

Q: What is the process of verifying sensor operation?

A: Simply observe the integrated LED indicator while the sensor is powered and installed. When a magnetic field from the cylinder's piston is detected, the LED illuminates, confirming a properly functioning sensor and the closing of the PNP NO contact.

Q: What are the key usage benefits of this magnetic sensor?

A: The sensor provides high-resolution, accurate position detection (1 mm) with a rapid response time (1 ms). Its robust and sealed design ensures long-term reliability, while features like the LED indicator and pre-wired connection simplify both setup and ongoing use.

Q: How does the BTH PSAZ-25-1/2-P ensure safety and durability?

A: Constructed with ABS plastic housing and rated IP67, the sensor is dust-tight and water-resistant, minimizing maintenance needs. Its high insulation resistance (100 M min at 500VDC) and strong shock/vibration tolerances make it dependable for demanding industrial settings.

Q: What is the maximum switching capacity of the sensor?

A: This sensor supports a maximum switching voltage of 100V DC and a switching current of up to 100 mA, accommodating a wide range of industrial control and automation applications.

View More Details

Get a Price/Quote Request To Call Back
