FENAC FNC-50H-10630V3600-R5 Encoder

6800 INR/Piece

Minimum Order Quantity : 1 Pieces

Get a Price/Quote

Request To Call Back

FENAC FNC-50H-10630V3600-R5 Encoder Price & Specifications

Wireless No

Weight Approx. 180 g

Voltage 5-30V DC

Usage Industrial Automation

Signal Type Digital Pulse

Sensor Type Incremental Optical Encoder

Sensitivity High Precision

Response Time <1 ms

Resolution 3600 PPR (Pulses Per Revolution)

Product Type Rotary Encoder

Power Consumption Max. 60 mA

Output RS422 Differential (Line Driver)

Operating Temperature -20A C to +80A C

Mounting Type Flange Mount

Measurement Range 0a 360A (Continuous)

Material Aluminum Alloy Body

Interface RS422

Input Shaft Rotation

IP Rating IP65

Function Position and Speed Sensing

Features Robust Design, High Resolution, Wide Voltage Input Range

Cable Length 2 meters

Application CNC Machines, Robotics, Packaging Machinery

Accuracy A 0.05A

About FENAC FNC-50H-10630V3600-R5 Encoder Detail

FENACFNC-50H-10630V3600-R5 Encoder- Dealer, Supplier

Weare dealer and supplier of FENACFNC-50H-10630V3600-R5 Encoder in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad, Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Weare dealer, supplier of various manufacture of Fenac Encoder.

Precision and Performance

Engineered to deliver accurate position and speed feedback, the FENAC FNC-50H-10630V3600-R5 offers a remarkable 3600 pulses per revolution and 0.05 accuracy. Its rapid response time (<1 ms) and RS422 output enable seamless integration with modern controllers.

Durable Industrial Build

Encased in an aluminum alloy body and designed with a 50 mm housing, the encoder withstands shocks up to 100G and vibrations from 10 to 2000Hz at 20G. IP65 protection, extended bearing life, and an operating range from -20C to +80C ensure dependable operation in tough factory settings.

Easy Integration and Versatile Application

This encoder connects via a 2-meter pre-wired cable and supports a wide input voltage (530V DC), making it suitable for use with PLCs, microcontrollers, and motion controllers. Its flange mount installation simplifies setup across CNCs, robotics, and packaging systems.

FAQs of FENAC FNC-50H-10630V3600-R5 Encoder:

Q: How do I install the FENAC FNC-50H-10630V3600-R5 Encoder in my automation system?

A: Installation involves mounting the encoder using its flange, connecting the solid shaft (8 mm) to the driven component, and wiring the 2-meter pre-wired cable to your controllers RS422 differential input. Ensure the system is powered off and follow appropriate wiring diagrams for RS422 interfaces.

Q: What controllers are compatible with this encoder model?

A: The encoder is compatible with PLCs, microcontrollers, and motion controllers that support RS422 differential signal input. This wide compatibility allows seamless integration into various industrial automation platforms.

Q: When is the FENAC FNC-50H-10630V3600-R5 particularly beneficial for industrial applications?

A: This model is ideal for situations requiring precise position and speed sensingsuch as CNC machines, robotics, and packaging machineryespecially where high resolution, reliability, and resistance to harsh conditions are critical.

Q: What are the main protection features of this encoder?

A: It is equipped with short circuit and reverse polarity protection, an IP65 ingress rating, and a durable aluminum alloy housing, enhancing its resistance to electrical and environmental hazards.

Q: Where can the encoder operate in terms of environmental conditions?

A: The encoder is designed for operation in environments with temperatures ranging from -20C to +80C and can be stored safely between -30C and +90C. It withstands shocks up to 100G and vibrations from 10 to 2000Hz at 20G.

Q: What process does the encoder use to sense position and speed?

A: It uses incremental optical sensing with a 3600 PPR resolution to measure angular position and rotational speed. The encoder outputs digital pulses via the RS422 interface, which controllers decode for precise feedback.

Q: What are the key benefits of using this encoder in automated machinery?

A: Key advantages include high measurement accuracy (0.05), rapid response time, long bearing life (50,000 hours typical), robust construction, and straightforward installation, leading to reduced downtime and consistent performance in industrial environments.
