Meanwell RSP-150-24
2600 INR/Piece
Minimum Order Quantity : 1 Pieces
Meanwell RSP-150-24 Price & Specifications
Working Temperature -30A C ~ +70A C
Weight 0.78 kg
Voltage Protection Overvoltage, Overcurrent, Short Circuit, Overtemperature
Storage Temperature -40A C ~ +85A C
Rated Power 156W
Rated Current 6.5A
Product Type AC-DC Single Output Enclosed Power Supply
Power Supply AC-DC Power Supply
Power Factor >0.95
Phase Single Phase
Output Type Single
Output Power 151.2 W
Output Frequency 47 ~ 63 Hz (Input Frequency)
Output Current 0 ~ 6.5A
Operating Temperature -30A C ~ +70A C
Noise Level <85mVp-p
Material Metal (Aluminum Casing)
Line Regulation A 0.5%
Input Voltage 88 - 264 VAC; 124 - 370 VDC
Features Ultra-low profile, built-in active PFC, high efficiency, cooling by free air convection, LED indicator for power on, 1U low profile, Protections: Short circuit / Overload / Over voltage / Over temperature
Efficiency 89%
Current Range 0 ~ 6.5A
Cooling Method Free Air Convection
Connector Type Screw Terminal Block
Application Industrial Automation, Control Systems, LED, Security, Test Equipment
About Meanwell RSP-150-24 Detail
MeanwellRSP-150-24 - Dealer, Supplier
We are dealer, and supplier of Meanwell power supply, smps in India, Mumbai, Delhi, Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi, Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal, Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore, Hyderabad, Kanpur, Goa, Vishakhapatnam, Cochin, Ernakulum, Ludhiana, Chandigarh, Baddi, Dehradun, China, Korea, Taiwan, Singapore, UAE, Dubai, Malaysia, Srilanka, Bangladesh, South Africa.
Ultra-Low Profile with High Efficiency
Measuring only 30mm in height, the RSP-150-24 fits tight spaces in control cabinets and industrial enclosures. Its 89% efficiency and active power factor correction (PFC) help reduce energy consumption and enhance system performance, while free air convection cooling reduces maintenance needs.
Comprehensive Protection and Compliance
Engineered for safety, the power supply features overvoltage, overcurrent, short circuit, and overtemperature protections. Complying with UL62368-1, TUV EN62368-1, and EAC TP TC 004 standards, it ensures reliable and safe operation in diverse applications and environments.
Flexible Control and Convenient Installation
The RSP-150-24 offers remote ON/OFF control and user-friendly screw terminal block connectors, simplifying integration and maintenance. The adjustable output voltage (21.628.8V) allows fine-tuning for various loads, making it versatile for OEMs, system integrators, and facilities managers.
