Shavison AS391-24V-S-OE

260 INR/Piece

Minimum Order Quantity : 1 Pieces

Get a Price/Quote

Request To Call Back

Shavison AS391-24V-S-OE Price & Specifications

Working Temperature -40A C to +70A C

Weight Approx. 70g

Usage Industrial Automation

Theory Electromagnetic Relay

Terminal Type Plug-in

Supply Terminal Screw Terminal

Size Standard

Rated Voltage 24V DC

Protect Feature Dust Cover

Product Type General Purpose Relay

Power Consumption Approx. 0.9W

Operate Time 15ms max.

Mechanical Life >10,000,000 operations

Insulation Resistance 100 MIC min. (at 500V DC)

Dimension (L*W*H) 35.5 x 21 x 27.5 mm

Dielectiric Strength 1500V AC, 1 min

Contact Resistance 50 mIC max.

Contact Material Silver Alloy

Contact Load 10A 250V AC / 10A 30V DC

Contact Form DPDT

Color Transparent Cover

Coil Voltage 24V DC

Coil Power 0.9W

Ambient Temperature -40A C to +70A C

About Shavison AS391-24V-S-OE Detail

ShavisonAS391-24V-S-OE - Dealer, Supplier

Weare dealer and supplier of Shavison AS391-24V-S-OE in India, Mumbai,Delhi, Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur,Vapi, Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore,Bhopal, Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad, Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia. We areDealer, Supplier of Shavison SMPS,Shavison Relay Module, Shavison Battery Charger.

Reliable Performance in Industrial Environments

Withstanding ambient temperatures from -40C to +70C and shock up to 10G, the AS391-24V-S-OE is engineered for demanding industrial settings. Its insulation resistance of 100 M (at 500V DC) and dielectric strength of 1500V AC make it suitable for critical applications where safety and reliability are vital. The relay's robust design and dust-protective transparent cover ensure uninterrupted service even in harsh working conditions.

Flexible and Easy Installation

The relay offers versatile mounting through panel or socket options, catering to diverse system layouts. Its plug-in terminal design and screw supply terminals make wiring straightforward, minimizing downtime during installation or servicing. The compact standard dimension of 35.5 x 21 x 27.5 mm and 70g approximate weight allow for seamless integration within control panels and automation systems.

FAQ's of Shavison AS391-24V-S-OE:

Q: How do I mount the Shavison AS391-24V-S-OE relay in my system?

A: The AS391-24V-S-OE can be installed using either panel mount or socket mount methods. Its plug-in terminal and screw terminal design facilitate easy wiring and replacement, catering to various industrial automation panel configurations.

Q: What are the primary benefits of using the AS391-24V-S-OE relay in industrial automation?

A: This relay offers robust reliability, supporting up to 10A at 250V AC/30V DC load, wide operational and storage temperature ranges, high mechanical life, and a transparent dust cover for added protection. The built-in LED indicator provides clear status updates, enhancing safety and convenience.

Q: Where is the AS391-24V-S-OE typically used?

A: It is most commonly used in industrial automation applications, including control panels, machinery, and process control systems, where high durability and reliable switching are required.

Q: What is the process for wiring and replacing this relay?

A: The relay features plug-in terminals and screw supply connections, making wiring or replacing the unit quick and straightforward. Simply secure the relay onto the socket or panel and connect your control and load wires to the screw terminals as per your panel layout.

Q: When should I consider replacing the relay?

A: Despite a mechanical life exceeding 10 million operations, relays should be inspected regularly and replaced if any deterioration in contact resistance, switching performance, or physical damage is observed.

Q: What usage precautions should I keep in mind for maximum longevity?

A: Ensure that load voltages and currents do not exceed specified ratings (10A/250V AC, 10A/30V DC), maintain the recommended ambient temperature (-40C to +70C), and avoid exposing the relay to excessive mechanical shock or vibration outside of its rated limits. Regular maintenance will optimize relay performance and service life.
