BTH BI-38S-1024-L5 Magnetic Sensor

5350 INR/Piece

Minimum Order Quantity : 1 Pieces

Get a Price/Quote

Request To Call Back

BTH BI-38S-1024-L5 Magnetic Sensor Price & Specifications

Wireless No

Weight Approx. 120g

Voltage 5 V to 24 V DC

Usage Industrial Automation, Position Feedback

Signal Type Digital Pulse

Sensor Type Magnetic Incremental Encoder

Sensitivity High

Response Time <1 ms

Resolution 1024 PPR (Pulses Per Revolution)

Product Type Magnetic Sensor

Power Consumption a 50 mA

Output Line Driver Output

Operating Temperature -20A C to +85A C

Mounting Type Flange Mounting

Measurement Range 0a 360A Continuous Detection

Material Aluminum Alloy Body

Interface TTL/RS422 Compatible

Input 5-24 V DC

IP Rating IP65

Function Position Detection / Sensing

Features Robust Design, High Precision, Easy Installation

Cable Length 2 meters

Application Rotary Sensing for Automation, Motion Control

Accuracy A 1%
