BTH PSAZ-300-1/2 Magnetic Sensor

2000 INR/Piece

Minimum Order Quantity : 1 Pieces

Get a Price/Quote

Request To Call Back

BTH PSAZ-300-1/2 Magnetic Sensor Price & Specifications

Wireless No

Weight 75 g

Voltage 12~24 VDC

Usage Automated Equipment, Industrial Automation

Signal Type Digital

Sensor Type Proximity, Magnetic

Sensitivity High

Response Time <1 ms

Resolution 1 mm

Product Type Magnetic Sensor

Power Consumption <15 mA

Output PNP/NO, NPN/NO

Operating Temperature -10A C to +60A C

Mounting Type Panel/Surface Mount

Measurement Range 0-300 mm

Material ABS Plastic Housing

Interface Wire Lead

Input Magnetic Field

IP Rating IP67

Function Position Sensing, Detection

Features Compact Design, Robust Housing, LED Indicator

Cable Length 2 m

Application Magnetic Field Detection, Process Control

Accuracy 1 mm

About BTH PSAZ-300-1/2 Magnetic Sensor Detail

BTHPSAZ-300-1/2 MagneticSensor- Dealer, Supplier

Weare dealer and supplier of PSAZ-300-1/2MagneticSensor in India, Mumbai, Delhi,Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur Vapi,Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal,Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad,Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia.

Weare dealer, supplier of various manufacture of Bth Motion, BthEncoder Bth Pressure, Bth Process & Sensor Controller, Bth ReedSensor, Bth Inductive Sensor, Bth Analog & Capacitive Sensor, BthSensor Cable, Bth Photo sensor , Bth Fiber Sensor, Bth LiquidSensing, Bth SSR, Bth TPR, Bth DC Supply, Bth Signal.

Precision Position Sensing

Engineered for excellent position detection, the PSAZ-300-1/2 sensor delivers a fine 1 mm accuracy across a 0300 mm range. Fast response times under 1 ms support real-time automation tasks, making it ideal for process control applications in demanding environments.

Durability and Environmental Resistance

The ABS plastic housing and IP67 ingress protection ensure long-term sensor reliability even in harsh conditions. Vibrations from 1055 Hz are tolerated, with sturdy mounting options and robust design supporting panel or surface installations in industrial settings.

Seamless Integration and Versatile Application

With compatibility for both PNP/NO and NPN/NO circuits, this sensor effortlessly integrates into a wide range of automated systems. The 2-meter pre-wired cable, clear LED indication, and compact form factor simplify installation and maintenance for distributors, manufacturers, and service providers.

FAQs of BTH PSAZ-300-1/2 Magnetic Sensor:

Q: How is the PSAZ-300-1/2 Magnetic Sensor typically used in automation systems?

A: The PSAZ-300-1/2 sensor is commonly applied in industrial automation for magnetic field detection and position sensing. Its high sensitivity and 1 mm accuracy make it suitable for process control, object detection, and automated equipment safety interlocks.

Q: What installation process must be followed for the PSAZ-300-1/2 sensor?

A: Installation involves mounting the sensor using its panel or surface mounting options and connecting the pre-wired 2-meter cable to the systems power (1224 VDC) and digital output interface. The sensors polarity protection and EMC compliance ensure straightforward setup without complex adjustments.

Q: Where are the benefits of using this sensor most apparent in industrial applications?

A: The main benefits include highly accurate position detection, robust waterproof housing (IP67), fast response times under 1 ms, and the ability to withstand vibrations and broad temperature ranges. These features enhance reliability and system uptime in demanding environments.

Q: When is the LED indicator on the PSAZ-300-1/2 sensor activated?

A: The red LED indicator lights up whenever the sensor detects the presence of a magnetic field within its specified range, providing immediate visual feedback for diagnostic and operational purposes.

Q: What distinguishes the PSAZ-300-1/2 Magnetic Sensor from other types of proximity sensors?

A: Unlike traditional proximity sensors, the PSAZ-300-1/2 is designed specifically for magnetic field detection. It features high resolution, rapid response, and environmental resistance, all within a compact, durable enclosure, making it uniquely suited for precise automation tasks.

Q: How does the device ensure operational reliability under harsh environmental conditions?

A: Its ABS plastic housing, IP67 rating, and vibration resistance allow the sensor to perform reliably in wet, dusty, or high-vibration industrial environments. The device also tolerates storage temperatures from -25C to +80C and operating humidity from 35% to 85% RH.
