Omron WL-1H1100 Limit Switch

618 INR/Piece

Minimum Order Quantity : 1 Pieces

Get a Price/Quote

Request To Call Back

Omron WL-1H1100 Limit Switch Price & Specifications

Weight Approx. 400g

Temperature Range -10A C to +80A C (no freezing)

Stoke 13 mm (Plunger total travel)

Size 48 x 40 x 104 mm

Response Time Instantaneous (Mechanical)

Rated Voltage 250V AC

Protection Level IP67

Product Type Limit Switch

Operating Temperature -10A C to +80A C

Number of Module Single

No Of Poles 2 Pole

Mounting Type Panel Mount/Direct Mount

Mechanical Life 10,000,000 operations min.

Max. Voltage 500V AC

Max. Current 10A

Material Die-cast Aluminum Alloy

Insulation Resistance 100MIC min. (at 500VDC)

Finish Type Matte/Enamel Coated

Current Rating 10A at 250VAC

Contact Resistance 25mIC max.

Color Grey / Black

Circuit Type SPDT

Automation Grade Manual

About Omron WL-1H1100 Limit Switch Detail

Omron WL-1H1100 Limit Switch Distributor, Dealer, Supplier Price in India.

We are Dealer, Supplier, Distributor of Omron WL-1H1100 Limit Switch in India, Omron Solid State Relay, Omron Proxiity Switch, Omron Photoelectric Sensor, Omron Fiber Optic Sensor optic Sensor, Omron Application Sensor, OmronEncoder, Omron Temperature Controller, Omron Timer, Omron Counter, Omron Power Supply, Omron SMPS, Omron Level Controller, Omron Relay, Omron VFD, Omron PLC, Omron HMI, Omron Limit Switch, Omron SSR, Omron Switches, Omron Timer

Apple Automation and Sensor Dealer, Supplier and Distributor of Omron Automation Products in India, Mmubai, Pune, Nashik, Aurangabad, Nagpur Vapi, Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore, Bhopal, Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore, Hyderabad, Kanpur, Goa, Vishakhapatnam, Cochin, Ernakulum, Ludhiana, Chandigarh, Baddi, Dehradun, China, Korea, Taiwan, Singapore, UAE, Dubai, Malaysia, Sri Lanka, Bangladesh, South Africa.

We stock various size, various make sensor, encoder like PNP, NPN, NO, NC, Realy Output, AC, DC, 2 wire, Three Wire, Cylindrical, Square type, Plug in Type, 230VAC, 10-30VDC, 24VDC, PPR, Various Amp Power Supply, HP Capacity VFD Drive, types of I/O PLC, Digital, Analog type, Line driver, counter, timer, temperature controller, Switches, Totem pole type Rotary Encoder, Incremental Encoder, Shaft Encoder, Hollow Shaft Encoder Etc.

Product Overview

Model: WL-1H1100

Brand: Omron

Model No - WL-1A100, WL-1A200, WL-1A300, WL-1H1100, WL-2A100, WL-2A104, WL-2A105, WL-2A110, WL-2A122, WL-2A130, WL-2A136, WL-2H1100, WL-3A100, WL-3A108, WL-3A200, WL-4A100, WL-9H100

Rugged and Reliable Construction

Built with a die-cast aluminum alloy housing and matte/enamel coating, the WL-1H1100 provides outstanding mechanical strength. Its fully sealed cover ensures protection against oil and dust, making it suitable for harsh industrial settings where reliability is crucial.

Enhanced Protection for Industrial Use

This limit switch holds an IP67 rating, ensuring resistance against water and dust ingress. The shock and vibration resistance further secure its performance in environments prone to heavy machinery movements, maintaining stable operation throughout its long service life.

Flexible Application and Easy Mounting

The WL-1H1100 offers panel and direct mounting options and supports installation via Pg13.5 conduit, accommodating various industrial automation requirements. Its SPDT circuit and NO/NC outputs make it suitable for complex control systems.

FAQ's of Omron WL-1H1100 Limit Switch:

Q: How is the Omron WL-1H1100 limit switch typically used in automation processes?

A: The Omron WL-1H1100 limit switch is commonly used to detect the presence or position of machine parts, providing instantaneous switching signals for automation systems. It acts as a reliable interface for machine safety and sequence control applications.

Q: What are the key benefits of the IP67-rated cover on this limit switch?

A: The IP67-rated cover ensures complete protection from dust and significant resistance to water, allowing the switch to function reliably in challenging industrial environments with exposure to oil and dust.

Q: When should the WL-1H1100 limit switch be chosen over other models?

A: Choose the WL-1H1100 when high durability, a fully sealed cover, robust shock and vibration resistance, and long mechanical/electrical life are essential for your process or environment.

Q: Where can this limit switch be installed in an industrial setup?

A: The WL-1H1100 is suited for both panel mount and direct mount applications, making it versatile for use on various machinery and conveyor systems within manufacturing plants and automation lines.

Q: What materials are used in the construction of this limit switch?

A: The switch is constructed with a die-cast aluminum alloy body, silver alloy contacts, and a matte/enamel coated finish for enhanced durability and corrosion resistance.

Q: How is the wiring connected to the WL-1H1100?

A: Connection is made through a Pg13.5 conduit entry, allowing secure cable attachment and strain relief for robust wiring in industrial applications.

Q: What is the process for replacing or mounting the WL-1H1100 limit switch?

A: To replace or mount, secure the switch using a mounting torque of 1.18 Nm, connect the wiring through the Pg13.5 conduit, and verify proper operation in accordance with manufacturer guidelines to ensure safe and effective installation.
