Shavison AS523-24V

580 INR/Piece

Minimum Order Quantity : 1 Pieces

Get a Price/Quote

Request To Call Back

Shavison AS523-24V Price & Specifications

Working Temperature -25A C to +55A C

Weight 50g

Usage Industrial automation, Control panel systems

Theory Electromagnetic Relay

Terminal Type Plug-In

Supply Terminal Screw Type

Size Standard Miniature

Rated Voltage 24V DC

Protect Feature Sealed Dust Cover

Product Type General Purpose Relay

Power Consumption Approx. 0.5W

Operate Time <20ms

Mechanical Life 10,000,000 Operations

Insulation Resistance >100MIC (500VDC)

Dimension (L*W*H) 28 x 21 x 37 mm

Dielectiric Strength 1,000Vrms In Between Open Contacts

Contact Resistance <100mIC (Initial)

Contact Material Silver Alloy

Contact Load 5A at 250V AC / 30V DC

Contact Form DPDT

Color Black & Clear

Coil Voltage 24V DC

Coil Power 0.5W

Ambient Temperature -25A C to +55A C

About Shavison AS523-24V Detail

ShavisonAS523-24V - Dealer, Supplier

Weare dealer and supplier of Shavison AS523-24V in India, Mumbai,Delhi, Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur,Vapi, Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore,Bhopal, Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad, Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia. We areDealer, Supplier of Shavison SMPS,Shavison Relay Module, Shavison Battery Charger.

Efficient Relay Solution for Industrial Automation

The Shavison AS523-24V relay delivers high reliability in automation and control panel operations with its robust DPDT contacts and sealed construction. Engineered for durability, it boasts a mechanical life of 10 million operations and superior insulation resistance, ensuring consistent performance in demanding environments.

Compact Design with Versatile Mounting Options

Measuring just 28 x 21 x 37 mm, the AS523-24V fits easily within standard miniature relay slots. Installers can benefit from both socket and PCB mounting flexibility, while its screw-type terminals simplify secure connections during integration into control panels and automation setups.

FAQ's of Shavison AS523-24V:

Q: How is the Shavison AS523-24V relay mounted in control panel systems?

A: The AS523-24V supports both socket and PCB mounting options, allowing versatile integration into control panels. Its screw-type supply terminals and plug-in design streamline installation and maintenance.

Q: What are the benefits of using the AS523-24V in industrial automation?

A: This relay offers quick operate and release times, high insulation resistance, and a sealed dust cover for dust protection. Its mechanical life of 10 million operations ensures longevity, resulting in fewer replacements and consistent automation performance.

Q: When should I use the AS523-24V relay in my automation project?

A: Employ this relay when you require dependable switching of up to 5A at 250V AC or 30V DC. It excels in environments where rapid and accurate switching is crucial, such as industrial automation and control panels.

Q: Where can the AS523-24V relay be sourced in India?

A: You can obtain the AS523-24V from distributors, dealers, manufacturers, suppliers, and wholesalers across India. It is widely available for purchase for both new installations and replacement needs.

Q: What is the process for connecting the AS523-24V relay in a system?

A: Simply use its screw-type terminals for secure wire connections. Insert the relay into the socket or PCB as per the chosen mounting style, and ensure the rated coil voltage of 24V DC is supplied for proper operation.

Q: What makes the AS523-24V relay suitable for harsh environments?

A: Its sealed dust cover, high insulation resistance (>100M at 500VDC), and operational temperature range from -25C to +55C make it resilient against contaminants and temperature fluctuations commonly found in industrial settings.

Q: How does the AS523-24V improve system efficiency?

A: With low power consumption (approx. 0.5W) and responsive operating times (<20ms), the relay minimizes energy usage and downtime, enhancing the overall efficiency and reliability of control systems.
