Shavison AS397-24V-OE

1000 INR/Piece

Minimum Order Quantity : 1 Pieces

Get a Price/Quote

Request To Call Back

Shavison AS397-24V-OE Price & Specifications

Working Temperature -30A C to +55A C

Weight Approx 74 g

Usage Control Panel, Industrial Automation

Theory Electromagnetic Relay

Terminal Type Plug-in

Supply Terminal Approx. 2 x 0.5 mmA

Size Standard Octal

Rated Voltage 24 VDC

Protect Feature Sealed Construction

Product Type General Purpose Relay

Power Consumption Approx. 0.9W

Operate Time 25 ms (Max)

Mechanical Life 10,000,000 operations (Min.)

Insulation Resistance 100 MIC Min. (500V DC)

Dimension (L*W*H) 30 x 32 x 39 mm

Dielectiric Strength 1500VAC, 50/60Hz for 1 min

Contact Resistance 50 mIC (Initial)

Contact Material Silver Alloy

Contact Load 10A @ 250VAC / 28VDC

Contact Form DPDT (2CO)

Color Transparent Cover (Relay)

Coil Voltage 24 V

Coil Power Approx. 0.9W

Ambient Temperature -30A C to +55A C

About Shavison AS397-24V-OE Detail

ShavisonAS397-24V-OE - Dealer, Supplier

Weare dealer and supplier of Shavison AS397-24V-OE in India, Mumbai,Delhi, Ahmedabad, Chennai, Kolkata, Pune, Nashik, Aurangabad, Nagpur,Vapi, Silvassa, Surat, Vadodara, Rajkot, Gandhidham, Morbi, Indore,Bhopal, Faridabad, Ghaziabad, Noida, Gurgaon, Coimbatore, Bangalore,Hyderabad, Kanpur, Goa, Visakhapatnam, Cochin, Ernakulam, Ludhiana,Chandigarh, Baddi, Dehradun, Sangli, Satara, Ichalkarnji, Solapur,Kupwad, Kolhapur, Pimpri, Chinchwad, Jalgaon, Surat, Baroda, Morbi,UAE, Bangladesh, Nepal, Bhutan, Dubai, Saudi Arabia, United ArabEmirates, Abu Dhabi, Bahrain, Qatar, Muscat, Oman, Sri Lanaka, SouthAfrica, Myanmar, Thailand, Vietnam, Jakarta, Indonesia. We areDealer, Supplier of Shavison SMPS,Shavison Relay Module, Shavison Battery Charger.

Designed for Control Panel Efficiency

The AS397-24V-OE relay stands out in industrial automation and control panels due to its robust build. With a quick 25 ms operate time and high insulation resistance of 100 M, it ensures reliable switching and long-term performance. Its octal standard size and plug-in terminals facilitate straightforward integration and replacement, minimizing downtime in your industrial setup.

Durable Construction and Reliable Performance

Constructed with a sealed body and a transparent cover, the AS397-24V-OE protects internal components from dust and contaminants while allowing quick visual checks. The silver alloy contacts ensure minimal resistance and superior conductive performance, supporting high switching loads and extending the relay's lifespan even in demanding environments.

FAQ's of Shavison AS397-24V-OE:

Q: How do I properly mount the Shavison AS397-24V-OE relay?

A: The AS397-24V-OE relay supports both panel and socket mounting. Use an 8-pin standard octal socket for a secure connection, and ensure supply terminals accommodate 2 x 0.5 mm2 wires for optimal performance.

Q: What environments are suitable for using this relay?

A: This relay operates efficiently between -30C and +55C, making it ideal for industrial automation and control panels in warehouses, factories, and other demanding industrial locations.

Q: What is the benefit of the relay's transparent cover and sealed construction?

A: The transparent cover enables easy visual inspection of the relay's internal state, while the sealed construction protects against dust and moisture, enhancing the device's durability and reliability.

Q: How does the Shavison AS397-24V-OE ensure operational safety?

A: With a dielectric strength of 1500VAC at 50/60Hz for one minute and insulation resistance of at least 100 M, the relay is engineered for secure electrical isolation and safe operation in critical control circuits.

Q: What contact loads can the relay handle and what materials are used?

A: It is capable of handling up to 10A at 250VAC or 28VDC with silver alloy DPDT contacts, ensuring both high load capacity and low contact resistance.

Q: Where is the AS397-24V-OE commonly distributed or installed?

A: This model is widely distributed and supplied across India by dealers, exporters, and industrial equipment suppliers, and is typically installed in control panels for automation, machinery, and process control.
